Approved Method: Electrical and Photometric Measurement of Fluorescent Lamps

Electrical and Photometric Measurement of Fluorescent Lamps

$50.00

For Member Pricing, Please Login

Member Price: $35.00

ANSI/IES LM-9-20
Document Type: Lighting Measurement and Testing (LM)

Available as a downloadable secure PDF only.

To stay current with all IES standards, we recommend subscribing to the The Lighting Library as an Individual or through your company as a Sustaining Member.

In stock

SKU: ANSI/IES LM-9-20 Category: Tag:

Product Description

Approved American National StandardThis Approved Method describes the procedures to be followed and the precautions to be observed in obtaining uniform and reproducible measurements of the electrical and photometric characteristics of fluorescent lamps under standard conditions in 60-Hz alternating current circuits and under high-frequency conditions (reference high-frequency circuits are operated at 25 kHz). In addition to linear fluorescent lamps, this document covers all U- and circular-shaped fluorescent lamps.

Page count: 12 pages
Publisher: Illuminating Engineering Society (2020)
SKU: ANSI/IES LM-9-20
ISBN-13: 978-0-87995-193-1

Chapters:

  • 1.0 Scope
    2.0 Normative References
    3.0 Nomenclature and Definitions
    4.0 Ambient and Physical Conditions
    5.0 Electrical Conditions
    6.0 Lamp Test Procedures
    7.0 Photometric Test Procedures
    8.0 Test Report


Citation Format:
Illuminating Engineering Society. ANSI/IES LM-9-20, Approved Method: Electrical and Photometric Measurement of Fluorescent Lamps. New York: IES; 2020.

CONTENTS

  • Introduction
  • 1.0 Scope
  • 2.0 Normative References
  • 3.0 Nomenclature and Definitions
  • 4.0 Ambient and Physical Conditions
  • 4.1 General
  • 4.2 Ambient Temperature
  • 4.3 Air Movement
  • 5.0 Electrical Conditions
  • 5.1 Waveshape
  • 5.2 Voltage Regulation
  • 5.3 Power Source Impedance
  • 5.4 Ballast
  • 5.5 Circuits and Lamp Connections
    5.5.1 Measurement Circuit Connections
    5.5.2 Preheat Start Lamps (Line Frequency)
    5.5.3 Preheat Start Lamps (High Frequency)
    5.5.4 Instant Start Lamps
    5.5.5 Rapid Start Lamps
    5.5.6 Cathode Power Requirements
  • 6.0 Lamp Test Procedures
  • 6.1 Lamp Orientation
  • 6.2 Lamp Stabilization
    6.2.1 Seasoning
    6.2.2 Pre-burning
    6.2.3 Determination of Stabilization Time
    6.2.4 Lamp Circuit Switching
  • 6.3 Use of the “Peak Lumen” Method
  • 6.4 Unusual Conditions
  • 6.5 Electrical Settings
  • 6.6 Electrical Instrumentation
    6.6.1 Instrument Tolerance
    6.6.2 Impedance Limitations
  • 7.0 Photometric Test Procedures
  • 7.1 Measurements with Photo-detectors
  • 7.2 Measurements with Spectral Detectors
  • 7.3 Normal Intensity (Candela)
  • 7.4 Intensity (Candela) Distribution
  • 7.5 Integrating Sphere Measurement
  • 7.6 Color Measurements
  • 8.0 Test Report
  • Informative Annex – Photometric Measurements of Lamps Using the Fixed Current Method
