Approved Method: Photometric Testing of Entertainment Lighting Luminaires Using Incandescent Filament Lamps or High Intensity Discharge Lamps

Photometric Testing of Entertainment Lighting Luminaires Using Incandescent Filament Lamps or High Intensity Discharge Lamps

$50.00

For Member Pricing, Please Login

Member Price: $35.00

ANSI/IES LM-73-18
Document Type: Lighting Measurement and Testing (LM)

Available as a downloadable secure PDF only.

To stay current with all IES standards, we recommend subscribing to the The Lighting Library as an Individual or through your company as a Sustaining Member.

In stock

SKU: ANSI/IES LM-73-18 Category: Tag:

Product Description

Approved American National StandardThis document describes a standard procedure by which entertainment lighting luminaires, specifically designed for use in the theater, TV environment, film studios, or on-location shoots, can be measured. Entertainment lighting luminaires usually have much narrower beam spreads than other luminaires. Therefore, different test methods and forms of presentation may be used. It should be noted that laser systems and scenic projectors are not covered by this document.

Page count: 14 pages
Publisher: Illuminating Engineering Society (2018)
SKU: ANSI/IES LM-73-18
ISBN-13: 978-0-87995-199-0

Chapters:

  • 1.0 Selecting Luminaires
    2.0 Basic Laboratory Conditions
    3.0 Preparation of Equipment for Test
    4.0 Testing by Goniophotometry
    5.0 Test Requirements for Specific Types of Luminaires
    6.0 Computation of Test Results and Test Report


Citation Format:
Illuminating Engineering Society. ANSI/IES LM-73-18, Approved Method: Photometric Testing of Entertainment Lighting Luminaires Using Incandescent Filament Lamps or High Intensity Discharge Lamps. New York: IES; 2018.
