Approved Method: Photometric Testing of Indoor Luminaires Using High Intensity Discharge or Incandescent Filament Lamps

Photometric Testing of Indoor Luminaires Using High Intensity Discharge or Incandescent Filament Lamps

$50.00

For Member Pricing, Please Login

Member Price: $35.00

ANSI/IES LM-46-20
Document Type: Lighting Measurement and Testing (LM)

Available as a downloadable secure PDF only.

To stay current with all IES standards, we recommend subscribing to the The Lighting Library as an Individual or through your company as a Sustaining Member.

In stock

SKU: ANSI/IES LM-46-20 Category: Tag:

Product Description

Approved American National StandardThis document provides a methodology for obtaining uniform test results under controlled laboratory conditions in measuring the luminous flux and intensity of luminaires with high intensity discharge (HID) lamps, including mercury vapor, high pressure sodium (HPS), and metal halide lamps. Also covered are similar luminaire types employing incandescent lamps, including tungsten-halogen lamps.

Page count: 15 pages
Publisher: Illuminating Engineering Society (2020)
SKU: ANSI/IES LM-46-20
ISBN-13: 978-0-87995-211-2

Chapters:

  • 1.0 Introduction and Scope
    2.0 Selection of Lamps
    3.0 Selection of Luminaires
    4.0 Test Conditions
    5.0 Preparation of Equipment for Test
    6.0 Test Procedure
    7.0 Photometric Measurement
    8.0 Indirect Luminaires
    9.0 Reporting Test Data
    10.0 Use of Computers and the IES Standard Format


Citation Format:
Illuminating Engineering Society. ANSI/IES LM-46-20, Approved Method: Photometric Testing of Indoor Luminaires Using High Intensity Discharge or Incandescent Filament Lamps. New York: IES; 2020.
