Approved Method: Electrical and Photometric Measurement of General Service Incandescent Filament Lamps

Electrical and Photometric Measurement of General Service Incandescent Filament Lamps

$50.00

For Member Pricing, Please Login

Member Price: $35.00

ANSI/IES LM-45-20
Document Type: Lighting Measurement and Testing (LM)

Available as a downloadable secure PDF only.

To stay current with all IES standards, we recommend subscribing to the The Lighting Library as an Individual or through your company as a Sustaining Member.

In stock

SKU: ANSI/IES LM-45-20 Category: Tag:

Product Description

Approved American National StandardThis document describes the procedures to be followed and the precautions to be observed in obtaining uniform and reproducible measurements of the electrical and photometric characteristics of general service incandescent filament lamps under standard conditions. The photometric information usually required is total luminous flux (lumens), luminous intensity (candelas) in one or more directions, and chromaticity. The electrical characteristics usually measured are lamp current, lamp voltage, and lamp power. Incandescent filament lamps are usually measured on direct current (DC), and the power can be calculated from voltage and current.

Page count: 6 pages
Publisher: Illuminating Engineering Society (2020)
SKU: ANSI/IES LM-45-20
ISBN-13: 978-0-87995-210-5

Chapters:

  • 1.0 Introduction and Scope
    2.0 Normative References
    3.0 Nomenclature and Definitions
    4.0 Ambient and Physical Conditions
    5.0 Electrical Conditions
    6.0 Lamp Test Procedures
    7.0 Photometric Test Procedures
    8.0 Test Report


Citation Format:
Illuminating Engineering Society. ANSI/IES LM-45-20, Approved Method: Electrical and Photometric Measurement of General Service Incandescent Filament Lamps. New York: IES; 2020.

CONTENTS

  • 1.0 Introduction and Scope
  • 1.1 Introduction
  • 1.2 Scope
  • 2.0 Normative References
  • 2.1 ANSI/IES LS-1-20
  • 2.2 ANSI/IES LM-54-20
  • 2.3 ANSI/IES LM-78-20
  • 3.0 Nomenclature and Definitions
  • 4.0 Ambient and Physical Conditions
  • 4.1 General
  • 4.2 Temperature
  • 4.3 Airflow
  • 4.4 Vibration
  • 5.0 Electrical Conditions
  • 5.1 Wave Shape
  • 5.2 Voltage or Current Regulation
  • 5.3 Circuits and Lamp Connections
  • 6.0 Lamp Test Procedures
  • 6.1 Lamp Position
  • 6.2 Lamp Stabilization
    6.2.1 Seasoning
    6.2.2 Pre-burning
    6.2.3 Determination of Stabilization Time
  • 6.3 Electrical Settings
  • 6.4 Electrical Instrumentation
    6.4.1 Instrument Tolerance
    6.4.2 Impedance Limitations
  • 7.0 Photometric Test Procedures
  • 7.1 Total Luminous Flux Measurements with an Integrating Sphere
    7.1.1 Photodetector
    7.1.2 Spectroradiometer
  • 7.2 Measuring Luminous Intensity
  • 7.3 Luminous Intensity Distribution
  • 7.4 Color Measurements
  • 8.0 Test Report
  • Informative References
